How to Replace and Mitre Your Door Architraves

The Step-by-Step DIY Guide

The DIY Checklist:
What You’ll Need

Upgrading old or water-damaged architraves completely transforms a room. To avoid multiple trips to the builders merchant, gather your complete product basket including structural mouldings, specialized fixings, finish products, and your essential safety gear before removing anything.

Man holding a measuring tape to assist in replacing and mitre your door architraves

1.

SAFETY
GEAR
(PPE)

Dust Mask (FFP2 Rated): Crucial to protect your lungs from fine particles when cutting MDF panels or sanding down wood fillers.

Safety Glasses: Essential eye protection against flying splinters or stray nails when operating a mitre saw or hammering.

2.

TOOLS &
EQUIPMENT

Mitre saw: A manual mitre box or electric compound mitre saw capable of making exact 45-degree bevel and angle cuts.

Hammer: Standard joinery claw hammer to drive in your finishing timber fasteners.

Nail punch: Essential tool to sink head pins completely beneath the wood surface without denting your new architrave profile.

Tape measure: For precise length checks and casing layout marking.

Wrecking Bar / Pry Bar & Chisel: Used together to gently lever old architrave lengths away from blockwork and door lining jamb frames.

Utility Knife: To score paint lines along walls, preventing old paint from tearing away your interior plaster.

3.

Materials, Fixings & Accessories

MDF architrave sets: Pre-primed MDF is highly recommended for stability and smooth paint finishes. Standard lengths usually come in 2.44m individual boards or convenient single-door pre-packed kits.

Wood adhesive: High-strength adhesive applied along the mitre joints and back faces to keep corners structurally locked forever.

Lost Head Nails or Brad Nails (40mm - 50mm): Slender, head-reduced nails designed to hold trim boards firmly into timber frames while staying easily camouflaged.

Wood filler: Smooth interior sandable paste to fill over nail dimples and joints.

Fine sandpaper: Grade 180-grit or 240-grit sanding sponges to buff filled regions flush before decoration.

Decorators Caulk: Flexible premium acrylic gap sealant to bridge the long junction lines where the wood moulding sits against uneven plaster walls.

Interior paint: Quality wood trim paint (Satinwood, Eggshell, or Gloss finish) to seal and colour your completed joinery.

DIY Pro Tip:

Place a small scrap piece of flat wood or thick cardboard under your pry bar's pivot point on the wall. This spreads the pressure load evenly, completely preventing the steel tool from punching holes in soft plaster wallboards.

The Joiner's Corner Secret:

Walls and frame jamb casings are rarely perfectly square. Before driving permanent pins into the wall frame, test-fit your vertical leg and top header angles together. If a tiny gap appears, fine-tune the cut face using a piece of fine sandpaper wrapped around a solid block.

Step-by-Step DIY Installation Guide

STEP

01

Removing the Old Architrave Safely

Score the Paint Seal:

Take your utility knife and carefully slice down the continuous paint or caulk line where the existing wood meet the wall. Skipping this step will cause the old paint to drag large chunks of finish plaster off the wall face.

Pry it Free:

Slide a cold chisel behind the old moulding right where a nail is located. Tap it with your hammer, then use a wrecking bar or pry bar to gently pop the board outward.

STEP

02

Prepping the Frame Surface

Clear Old Fixings:

Pull away any old rusty brad pins left stuck in the timber door lining frame using pliers or the claw end of your hammer.

Clean the Casing Face:

Scrap away remaining chunks of brittle caulking adhesive or loose splinters until the sub-frame face sits flat, clean, and sound.

STEP

03

Measuring and Setting Your Reveal Line

Architrave should never sit completely flush with the very inner edge of the door frame lining. It must be set back slightly to create a clean, uniform step-back step called a reveal or margin.

For standard doors, mark a light pencil line exactly 5mm back from the inner edge of the structural frame casing leg on all three sides (left jamb, right jamb, and top header).
The internal corners where these 5mm layout marks cross are your master reference points for length measurements.

STEP

04

Making the Perfect 45-Degree Mitre Cuts

Measure the Top Header:

Measure the horizontal gap length between your left and right crossing margin points. This dimension represents the absolute shortest bottom edge of your top header architrave piece.

Cut the Header Piece:

Place your board flat in the mitre saw. Swing the angle arm exactly to 45 degrees. Cut an outward angle from your mark so that the top edge of the board extends further out than the bottom edge. Mirror this on the opposite side to form a neat trapezoid shape.

Cut the Vertical Legs:

Measure from the floor line straight up to your top horizontal margin pencil mark. Mark this length on the inside edge of your vertical trim leg. Cut a single 45-degree angle starting from this point heading outward.

STEP

05

Applying Adhesive and Pinning Home

Apply Back Bonding:

Run a wavy bead of premium wood adhesive down the rear face of your prepared architrave board.

Lock the Mitre Corner:

Smear a thin layer of wood adhesive directly onto the porous 45-degree cut raw faces. Bring the vertical side leg and top piece together tightly.

Drive the Lost Head Nails:

Hold the trim piece perfectly steady on your 5mm pencil guide lines. Drive 40mm - 50mm lost head nails through the face of the moulding directly into the timber frame underneath. Space your fasteners roughly 300mm to 400mm apart.

Punch the Heads:

Place your nail punch flat onto each driven nail head. Give it a gentle tap with the hammer to sink the nail head roughly 1mm to 2mm below the face surface of the wood moulding.

STEP

06

Filling, Caulking, and Fine Decoration finishes

Mask the Dimples:

Press a small pea-sized dab of wood filler into every punched nail crater and over the tight hairline center of the 45-degree corner mitre seam. Allow it to fully harden for 30 minutes.

Sand it Back:

Put on your FFP2 dust mask and safety glasses. Use your fine sandpaper to buff the dry filler patches smoothly back until they feel flush to your hand. Wipe clean.

Run the Acrylic Caulk:

Gun a clean, continuous line of decorators caulk down the long gaps where the outer trim edges border the plaster wall. Smooth the bead down instantly using a damp finger or wiping cloth tool.

Final Paint Application:

Apply one to two light coats of your chosen interior wood trim paint across the primed wood to complete your clean architectural upgrade.

How to Replace and Mitre Your Door Architraves: The Ultimate Irish DIY Guide

Interactive Door Architrave Project Calculator

1. Door Frame Dimensions

Average Door Height (metres):

Average Door Width (metres):

Total Number of Doors to Trim:

2. Material Profile Settings

Architrave Profile Face Width (mm):

Architrave Framing Side Mode:

Material Wastage Safety Buffer:

Visual Door Frame Blueprint Concept

Estimated Project Basket Total

Total Linear Timber Required: 0.00 metres

Individual 2.44m Architrave Lengths: 0 pcs

40mm - 50mm Lost Head Nails: 1 Pack

High-Strength Wood Adhesive: 0 Tube(s)

Premium Interior Decorators Caulk: 0 Tube(s)

Smooth Interior Wood Filler: 1 Tub

Fine-Grit Sanding Foam Pads: 1 Pack

750ml Interior Trim Paint Tins: 1 Tin

Standard Irish Joinery Estimation Matrix:
• Moulding Supply Yield: Sized out around standard trade production lengths running at 2.44m per single stock profile board.
• Consumables Ratio: Adhesive and flexible caulking compound use rates expect roughly 1 full tube spread distribution across every 4 complete standard residential internal single-door opening faces.
